BORAJ-V4 DUAL-BAND


Highlights
  • » 4-array antenna system
  • » Improves the safety of satellite navigation in various platforms
  • » Prevents GNSS jamming caused by Jammers
  • » With anti-spoofing feature
  • » When used with SAJ, BORAJ provides up much higher suppress on of unwanted signals


Download Catalog

Effective Bands L1, B1, G1, E1 + L2 or L5
Suppression Rate (1–3 Source) 83 dB – 73 dB
Effective Angles Phi Angle: 0° to 360°
Theta Angle: -90° to +90°
Supply Voltage 12–15 VDC
Power Consumption 10W
Operating Temperature -40°C to +85°C
Storage Temperature -45°C to +85°C
Humidity / Waterproof 95% / IP67
Dimensions / Weight 149mm × 130mm × 38mm / 360 g
Interface Micro-D (customizable)
Protocol NMEA0183 Protocol
Pixhawk Compatible Yes
